A residential solar energy system integrates one Menred ESS LFP.6144.W unit, rated at 6.144kWh, paired directly with one SRNE hybrid inverter. This 1:1 configuration offers a minimal footprint solution suitable for homes with limited space or moderate daily energy needs.
The LFP.6144.W operates at a nominal voltage of 51.2Vdc and supports a maximum continuous charge/discharge current of 120A, compatible with hybrid inverters up to 6000W. The unit is certified to IEC 62619:2022, IEC 61000-1/3, and UN38.3/MSDS standards, ensuring compliance with international safety and transport regulations.
Communication between the battery management system and the inverter is handled via CAN or RS485 protocol, selectable on the built-in touchscreen interface. The system also supports Wi-Fi monitoring through a mobile application, providing real-time access to state of charge, voltage, temperature, and cycle count. An optional LED display is available for local status indication.
The unit measures 514×332×230mm and weighs 32kg, designed for wall mounting in utility closets or garages. As a lithium battery solution, it delivers reliable evening power and short-term backup for essential loads such as lighting and refrigeration.
Standard warranty is 5 years, with a 10-year option available. The modular design allows for future expansion — up to 16 units can be paralleled to achieve a total capacity of 98.24kWh.
